Stage 1
A large, fully equipped soundstage ideal for feature films, television, and commercial productions. Designed for flexibility and acoustic control.
Dimensions:
WorkingHeight - 37ft/11.3m
Width - 131ft/40m
Length - 146ft/45m
Power:
4x 400a production panel ( 2 with full set of power locks and 1 x 32A/3P, 1 x63A/3P and 1 x 125A/3 Phase sockets
16x 32A/3 Phase commando units
32x 13A/1 double switched sockets
Internalhouse lighting
Exteriorlighting for surrounding areas
Rigging:
13x Runway beams
7,500kgper truss
Maximum500kg per point
Floor loadings:
100kNper m2, 44kN per 200mm x 200mm point
Acoustic rating:
NR-25
Equipment:
75x 1T rated block & tackles
WirelessRed, light and bell
WirelessAccess Points
Internalducting for winter heating, which can also be used for cooling
Access & Ingress
2x Pedestrian doors into acoustic vestibules
1x Accessible ramp, 1 x entrance steps to vestibules from exterior
1x 5m x 6m elephant door with internal roller shutter with ramp access
4x acoustic cable entry hatches
Fire Detection systems:
Laserfire detection systems in roof
Multipleair sampling detectors
